Good-Ark Semicondutor Super Fast Recovery Rectifiers

Rectifiers

Super Fast Recovery Rectifiers

Diodes
Rectifiers
Bridge Rectifiers
Protection Devices
Mosfets
Transistors
MEMS
Wafer / Bare Die
Part Number Data
Sheet 		Package VRRM
(V) 		IF (AV)
(A) 		IFSM
(A) 		VF
(V) 		IR
(uA) 		trr
(nS)
Filter
Filter
Filter
Filter
Filter
Filter
Filter
Clear All Filters
1S1G R-1 50 1.0 30 0.95 5 35
1S2G R-1 100 1.0 30 0.95 5 35
1S3G R-1 150 1.0 30 0.95 5 35
1S4G R-1 200 1.0 30 0.95 5 35
1S5G R-1 300 1.0 30 1.30 5 35
1S6G R-1 400 1.0 30 1.30 5 35
1S7G R-1 600 1.0 30 1.70 5 35
1S8G R-1 800 1.0 30 1.70 5 35
1S9G R-1 1000 1.0 30 1.70 5 35
AES3AB DO-214AA (SMB) 50 3.0 100 0.92 10 35
AES3BB DO-214AA (SMB) 100 3.0 100 0.92 10 35
AES3CB DO-214AA (SMB) 150 3.0 100 0.92 10 35
AES3DB DO-214AA (SMB) 200 3.0 100 0.92 10 35
AES3FB DO-214AA (SMB) 300 3.0 100 1.25 10 35
AES3GB DO-214AA (SMB) 400 3.0 100 1.25 10 35
AES3JB DO-214AA (SMB) 600 3.0 100 1.70 10 35
AES3KB DO-214AA (SMB) 800 3.0 100 1.70 10 35
AES3MB DO-214AA (SMB) 1000 3.0 100 1.70 10 35
ES1A DO-214AC (SMA) 50 1.0 30 0.95 5 35
ES1B DO-214AC (SMA) 100 1.0 30 0.95 5 35
ES1C DO-214AC (SMA) 150 1.0 30 0.95 5 35
ES1D DO-214AC (SMA) 200 1.0 30 0.95 5 35
ES1F DO-214AC (SMA) 300 1.0 30 1.30 5 35
ES1G DO-214AC (SMA) 400 1.0 30 1.30 5 35
ES1J DO-214AC (SMA) 600 1.0 30 1.70 5 35
ES1K DO-214AC (SMA) 800 1.0 30 1.70 5 35
ES1M DO-214AC (SMA) 1000 1.0 30 1.70 5 35
ES2A DO-214AA (SMB) 50 2.0 50 0.95 10 35
ES2AA DO-214AC (SMA) 50 2.0 50 0.92 5 25
ES2B DO-214AA (SMB) 100 2.0 50 0.95 10 35
ES2BA DO-214AC (SMA) 100 2.0 50 0.92 5 25
ES2C DO-214AA (SMB) 150 2.0 50 0.95 10 35
ES2CA DO-214AC (SMA) 150 2.0 50 0.92 5 25
ES2D DO-214AA (SMB) 200 2.0 50 0.95 10 35
ES2DA DO-214AC (SMA) 200 2.0 50 0.92 5 25
ES2F DO-214AA (SMB) 300 2.0 50 1.30 10 35
ES2FA DO-214AC (SMA) 300 2.0 50 1.25 5 25
ES2G DO-214AA (SMB) 400 2.0 50 1.30 10 35
ES2GA DO-214AC (SMA) 400 2.0 50 1.25 5 25
ES2J DO-214AA (SMB) 600 2.0 50 1.70 10 35
ES2JA DO-214AC (SMA) 600 2.0 50 1.70 5 25
ES2K DO-214AA (SMB) 800 2.0 50 1.70 10 35
ES2KA DO-214AC (SMA) 800 2.0 50 1.70 5 25
ES2M DO-214AA (SMB) 1000 2.0 50 1.70 10 35
ES2MA DO-214AC (SMA) 1000 2.0 50 1.70 5 25
ES3A DO-214AB (SMC) 50 3.0 100 0.95 10 35
ES3AB DO-214AA (SMB) 50 3.0 100 0.92 10 35
ES3B DO-214AB (SMC) 100 3.0 100 0.95 10 35
ES3BB DO-214AA (SMB) 100 3.0 100 0.92 10 35
ES3C DO-214AB (SMC) 150 3.0 100 0.95 10 35
ES3CB DO-214AA (SMB) 150 3.0 100 0.92 10 35
ES3D DO-214AB (SMC) 200 3.0 100 0.95 10 35
ES3DB DO-214AA (SMB) 200 3.0 100 0.92 10 35
ES3F DO-214AB (SMC) 300 3.0 100 1.30 10 35
ES3FB DO-214AA (SMB) 300 3.0 100 1.25 10 35
ES3G DO-214AB (SMC) 400 3.0 100 1.30 10 35
ES3GB DO-214AA (SMB) 400 3.0 100 1.25 10 35
ES3J DO-214AB (SMC) 600 3.0 100 1.70 10 35
ES3JB DO-214AA (SMB) 600 3.0 100 1.70 10 35
ES3K DO-214AB (SMC) 800 3.0 100 1.70 10 35
ES3KB DO-214AA (SMB) 800 3.0 100 1.70 10 35
ES3M DO-214AB (SMC) 1000 3.0 100 1.70 10 35
ES3MB DO-214AA (SMB) 1000 3.0 100 1.70 10 35
ES5A DO-214AB (SMC) 50 5.0 150 0.95 5 35
ES5B DO-214AB (SMC) 100 5.0 150 0.95 5 35
ES5C DO-214AB (SMC) 150 5.0 150 0.95 5 35
ES5D DO-214AB (SMC) 200 5.0 150 0.95 5 35
ES5F DO-214AB (SMC) 300 5.0 150 1.40 5 35
ES5G DO-214AB (SMC) 400 5.0 150 1.40 5 35
ES5J DO-214AB (SMC) 600 5.0 150 1.70 5 35
FU1 eSGA (SOD-123FL) 50 1.0 30 0.95 5 35
FU2 eSGA (SOD-123FL) 100 1.0 30 0.95 5 35
FU3 eSGA (SOD-123FL) 200 1.0 30 0.95 5 35
FU4 eSGA (SOD-123FL) 400 1.0 30 1.30 5 35
FU5 eSGA (SOD-123FL) 600 1.0 30 1.70 5 35
GES3AB DO-214AA (SMB) 50 3.0 100 0.92 10 35
GES3BB DO-214AA (SMB) 100 3.0 100 0.92 10 35
GES3CB DO-214AA (SMB) 150 3.0 100 0.92 10 35
GES3DB DO-214AA (SMB) 200 3.0 100 0.92 10 35
GES3FB DO-214AA (SMB) 300 3.0 100 1.25 10 35
GES3GB DO-214AA (SMB) 400 3.0 100 1.25 10 35
GES3JB DO-214AA (SMB) 600 3.0 100 1.70 10 35
GES3KB DO-214AA (SMB) 800 3.0 100 1.70 10 35
GES3MB DO-214AA (SMB) 1000 3.0 100 1.70 10 35
GSGC0503U eSGC (TO-277) 200 5.0 150 0.95 10 35
GSGC0504U eSGC (TO-277) 400 5.0 150 1.30 10 35
GSGC0505U eSGC (TO-277) 600 5.0 150 1.70 10 35
GSGC0506U eSGC (TO-277) 800 5.0 150 1.70 10 35
GSGP3U eSGP (SOD-323F) 200 1.0 25 0.95 5 35
GSGP4U eSGP (SOD-323F) 400 1.0 25 1.30 5 35
GSGP5U eSGP (SOD-323F) 600 1.0 25 1.70 5 35
GSL2U1 eSGB (SMAF) 50 2.0 50 1.00 5 35
GSL2U2 eSGB (SMAF) 100 2.0 50 1.00 5 35
GSL2U3 eSGB (SMAF) 200 2.0 50 1.00 5 35
GSL2U4 eSGB (SMAF) 400 2.0 50 1.30 5 35
GSL2U5 eSGB (SMAF) 600 2.0 50 1.70 5 35
GSMUR1060F ITO-220-AC 600 10.0 120 1.60 5 35
GSPU1 iSGA (SOD-123HS) 50 1.0 30 0.95 5 35
GSPU2 iSGA (SOD-123HS) 100 1.0 30 0.95 5 35
GSPU3 iSGA (SOD-123HS) 200 1.0 30 0.95 5 35
GSPU4 iSGA (SOD-123HS) 400 1.0 30 1.30 5 35
GSPU5 iSGA (SOD-123HS) 600 1.0 30 1.70 5 35
LU1 eSGB (SMAF) 50 1.0 30 1.00 5 35
LU2 eSGB (SMAF) 100 1.0 30 1.00 5 35
LU3 eSGB (SMAF) 200 1.0 30 1.00 5 35
LU4 eSGB (SMAF) 400 1.0 30 1.30 5 35
LU5 eSGB (SMAF) 600 1.0 30 1.70 5 35
MFU1 eSGA (SOD-123FL) 50 1.0 30 0.95 5 35
MFU2 eSGA (SOD-123FL) 100 1.0 30 0.95 5 35
MFU3 eSGA (SOD-123FL) 200 1.0 30 0.95 5 35
MFU4 eSGA (SOD-123FL) 400 1.0 30 1.30 5 35
MFU5 eSGA (SOD-123FL) 600 1.0 30 1.70 5 35
MUR1040 TO-220-AC 400 10.0 125 1.40 10 35
MUR1040CT TO-220-AB 400 10.0 120 1.40 10 35
MUR1040F ITO-220-AC 400 10.0 125 1.40 10 35
MUR1040FCT ITO-220-AB 400 10.0 120 1.40 10 35
MUR120 DO-204AC (DO-15) 200 1.0 35 0.88 2 25
MUR1620CT TO-220-AB 200 16.0 125 1.00 10 35
MUR1620FCT ITO-220-AB 200 16.0 125 1.00 10 35
MUR2020CT TO-220-AB 200 20.0 125 1.10 10 35
MUR2020FCT ITO-220-AB 200 20.0 125 1.10 10 35
MUR420 DO-201AD 200 4.0 125 0.88 5 25
MUR520 TO-220-AC 200 5.0 90 0.96 10 35
MUR520F ITO-220-AC 200 5.0 90 0.96 10 35
MUR840 TO-220-AC 400 8.0 125 1.30 10 35
MUR840F ITO-220-AC 400 8.0 125 1.30 10 35
MURB1620CT TO-263 (D2PAK) 200 16.0 125 1.00 10 35
MURB820 TO-263 (D2PAK) 200 8.0 125 1.00 10 35
MURD1040 TO-252(DPAK) 400 10.0 100 1.40 10 35
MURS120 DO-214AA (SMB) 200 1.0 40 0.88 2 25
MURS120A DO-214AC (SMA) 200 1.0 40 0.88 2 25
MURS320 DO-214AB (SMC) 200 3.0 80 0.88 5 25
SF11 DO-204AL (DO-41) 50 1.0 30 0.95 5 35
SF11S A-405 50 1.0 30 0.95 5 35
SF12 DO-204AL (DO-41) 100 1.0 30 0.95 5 35
SF12S A-405 100 1.0 30 0.95 5 35
SF13 DO-204AL (DO-41) 150 1.0 30 0.95 5 35
SF13S A-405 150 1.0 30 0.95 5 35
SF14 DO-204AL (DO-41) 200 1.0 30 0.95 5 35
SF14S A-405 200 1.0 30 0.95 5 35
SF15 DO-204AL (DO-41) 300 1.0 30 1.30 5 35
SF15S A-405 300 1.0 30 1.30 5 35
SF16 DO-204AL (DO-41) 400 1.0 30 1.30 5 35
SF16S A-405 400 1.0 30 1.30 5 35
SF17 DO-204AL (DO-41) 600 1.0 30 1.70 5 35
SF17S A-405 600 1.0 30 1.70 5 35
SF18 DO-204AL (DO-41) 800 1.0 30 1.70 5 35
SF18S A-405 800 1.0 30 1.70 5 35
SF19 DO-204AL (DO-41) 1000 1.0 30 1.70 5 35
SF19S A-405 1000 1.0 30 1.70 5 35
SF21 DO-204AC (DO-15) 50 2.0 50 0.95 5 35
SF22 DO-204AC (DO-15) 100 2.0 50 0.95 5 35
SF23 DO-204AC (DO-15) 150 2.0 50 0.95 5 35
SF24 DO-204AC (DO-15) 200 2.0 50 0.95 5 35
SF25 DO-204AC (DO-15) 300 2.0 50 1.30 5 35
SF26 DO-204AC (DO-15) 400 2.0 50 1.30 5 35
SF27 DO-204AC (DO-15) 600 2.0 50 1.70 5 35
SF28 DO-204AC (DO-15) 800 2.0 50 1.70 5 35
SF29 DO-204AC (DO-15) 1000 2.0 50 1.70 5 35
SF301 DO-201AD 50 3.0 125 0.95 5 35
SF302 DO-201AD 100 3.0 125 0.95 5 35
SF303 DO-201AD 150 3.0 125 0.95 5 35
SF304 DO-201AD 200 3.0 125 0.95 5 35
SF305 DO-201AD 300 3.0 125 1.30 5 35
SF306 DO-201AD 400 3.0 125 1.30 5 35
SF307 DO-201AD 600 3.0 125 1.70 5 35
SF308 DO-201AD 800 3.0 125 1.70 5 35
SF309 DO-201AD 1000 3.0 125 1.70 5 35
SF31 DO-201AD 50 3.0 125 0.95 5 35
SF32 DO-201AD 100 3.0 125 0.95 5 35
SF33 DO-201AD 150 3.0 125 0.95 5 35
SF34 DO-201AD 200 3.0 125 0.95 5 35
SF35 DO-201AD 300 3.0 125 1.30 5 35
SF36 DO-201AD 400 3.0 125 1.30 5 35
SF37 DO-201AD 600 3.0 125 1.70 5 35
SF38 DO-201AD 800 3.0 125 1.70 5 35
SF39 DO-201AD 1000 3.0 125 1.70 5 35
SF41 DO-201AD 50 4.0 150 0.95 5 35
SF42 DO-201AD 100 4.0 150 0.95 5 35
SF43 DO-201AD 150 4.0 150 0.95 5 35
SF44 DO-201AD 200 4.0 150 0.95 5 35
SF45 DO-201AD 300 4.0 150 1.25 5 40
SF46 DO-201AD 400 4.0 150 1.25 5 40
SF47 DO-201AD 600 4.0 150 1.30 5 50
SF48 DO-201AD 800 4.0 150 1.70 5 50
SF49 DO-201AD 1000 4.0 150 1.70 5 50
SF51 DO-201AD 50 5.0 150 0.95 5 35
SF52 DO-201AD 100 5.0 150 0.95 5 35
SF53 DO-201AD 150 5.0 150 0.95 5 35
SF54 DO-201AD 200 5.0 150 0.95 5 35
SF55 DO-201AD 300 5.0 150 1.25 5 35
SF56 DO-201AD 400 5.0 150 1.25 5 35
SF57 DO-201AD 600 5.0 150 1.30 5 35
SF58 DO-201AD 800 5.0 150 1.70 5 35
SF59 DO-201AD 1000 5.0 150 1.70 5 35
SF61 DO-201AD 50 6.0 150 0.98 5 35
SF62 DO-201AD 100 6.0 150 0.98 5 35
SF63 DO-201AD 150 6.0 150 0.98 5 35
SF64 DO-201AD 200 6.0 150 0.98 5 35
SF65 DO-201AD 300 6.0 150 1.30 5 35
SF66 DO-201AD 400 6.0 150 1.30 5 35
SF67 DO-201AD 600 6.0 150 1.70 5 35
SF68 DO-201AD 800 6.0 150 1.70 5 35
SF69 DO-201AD 1000 6.0 150 1.70 5 35
SMUR1060 TO-220-AC 600 10.0 100 2.20 10 25
SMUR1060F ITO-220-AC 600 10.0 100 2.20 10 25
SMURP460 Power QFN5x6 600 4.0 90 1.50 10 35
SMURP560 PQFN5x6 600 5.0 90 1.60 10 35
